NET CAMERA Q6086-E PTZ/DOME 03188-002 AXIS

NET CAMERA Q6086-E PTZ/DOME 03188-002 AXIS
Ean:
7331021090392
Price:
5,077.58 Eur
In stock in LV warehouse

1-2 days

Fast delivery

40+

Countries shipped products

14 years

In IT market

2000+

B2B customers

Camera
Camera pan control Yes
Camera pixel size 2.9 µm
Camera shutter speed 1/49500 - 2 s
Camera tilt control Yes
Lens viewing angle, horizontal 61.5 °
Lens viewing angle, vertical 37.3 °
Minimum illumination 0.009 lx
Pan range 0 - 360 °
Pan speed 500 °/sec
Tilt angle range -90 - 0 °
Tilt speed 500 °/sec
Design
Fog proof Yes
Form factor Dome
Housing material Aluminium/Polycarbonate (PC)
IK code IK10
International Protection (IP) code IP66
Mounting type Ceiling
Product colour Black/White
Protection features Wear resistant
Image sensor
Optical sensor size 1/2 "
Progressive scan Yes
Sensor type CMOS
Number of sensors 1
Lens system
Auto focus Yes
Closest focusing distance 3 m
Detect distance (tele) 3118.4 m
Detect distance (wide) 92.6 m
Digital zoom 12 x
Focal length range 6.64 - 225.5 mm
Identify distance (tele) 311.8 m
Identify distance (wide) 9.3 m
Maximum aperture number 5.1
Minimum aperture number 1.7
Number of lenses 1
Observe distance (tele) 1237.5 m
Observe distance (wide) 36.7 m
Optical zoom 32 x
Recognize distance (tele) 623.6 m
Recognize distance (wide) 18.5 m
Zoom capability Yes
Network
Ethernet interface type Fast Ethernet/Gigabit Ethernet
Ethernet LAN Yes
Networking standards IEEE 802.1AE/IEEE 802.1ar/IEEE 802.1x/IEEE 802.3bt
Streaming method Multicast
Supported network protocols IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4
Operational conditions
Operating relative humidity (H-H) 10 - 100 %
Operating temperature (T-T) -50 - 55 °C
Storage relative humidity (H-H) 5 - 95 %
Storage temperature (T-T) -40 - 65 °C
Other features
Doesn't contain CFR/PVC/BFR
Packaging content
Number of cameras 1
Performance
Auto-tracking Yes
Certification CE, FCC, ICES, KC, VCCI
Connectivity technology Wired
Day/night mode Yes
Infrared (IR) cut-off filter Yes
Placement supported Outdoor
Preset points Yes
PTZ control Yes
PTZ modes Preset point
Tour recording Yes
Type IP security camera
Wide Dynamic Range (WDR) Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
Power
Power consumption (max) 51 W
Power consumption (typical) 10 W
Power source type PoE
Security
Alert notification type E-mail
HTTPS encryption Yes
Human and vehicle targets classification Yes
Intelligent Video Surveillance (IVS) system features Abandoned object/Crossing line
Password protection Yes
Pixel counter Yes
Security algorithms HTTPS/TLS
Specification
Units per Shipping Box 1
Unit Calculated Volume 0.03441 cubm
Unit Calculated Weight 6.1 kg
Summary Axis Q6086-E PTZ. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Black, Form factor: Dome. Minimum illumination: 0.009 lx, Lens viewing angle, horizontal: 61.5°, Lens viewing angle, vertical: 37.3°. Sensor type: CMOS, Optical sensor size: 25.4 / 2 mm (1 / 2"). Optical zoom: 32x, Digital zoom: 12x, Focal length range: 6.64 - 225.5 mm
Category Code FNC
Unit Box Height 0.31
Unit Box Length 0.37
Unit Box Width 0.3
Storage
Card reader integrated Yes
Compatible memory cards SD/SDHC/SDXC
Flash memory 8192 MB
RAM capacity 4096 MB
Sustainability
Compliance certificates REACH/RoHS/Trade Agreements Act (TAA)
Video
Bit rate control Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Frame rate 60 fps
Image quality adjustment Brightness/Contrast/Saturation/Sharpness
Maximum resolution 2688 x 1512 pixels
Noise reduction Yes
Noise reduction technology 2D noise reduction,3D noise reduction
Supported graphics resolutions 2688 x 1512/640 x 360
Text caption overlay Yes
Total megapixels 4 MP
Video compression formats H.262/H.264/H.265/M-JPEG/MPEG4
Video streaming Yes
Weight & dimensions
Depth 264 mm
Height 279 mm
Weight 4100 g
Width 264 mm
