Msi

MSI AMD B850 SAM5 ATX

Mainboard|MSI|AMD B850|SAM5|ATX|Memory DDR5|Memory slots 4|B850GAMINGPLUSWIFIPZ
Ean:
4711377365284
Price:
250.59 Eur
In stock in LV warehouse

1-2 days

Fast delivery

40+

Countries shipped products

14 years

In IT market

2000+

B2B customers

BIOS
ACPI version 6.5
BIOS type UEFI AMI
System Management BIOS (SMBIOS) version 3.7
Expansion slots
1st M.2 highest PCI Express generation 5.0
1st M.2 largest key size 2280
2nd M.2 highest PCI Express generation 4.0
2nd M.2 largest key size 22110
3rd M.2 highest PCI Express generation 4.0
3rd M.2 largest key size 2280
Number of M.2 (M) slots 3
PCI Express x16 (Gen 3.x) slots 2
PCI Express x16 (Gen 4.x) slots 1
PCI Express x16 (Gen 5.x) slots 1
Features
Audio chip Realtek ALC897
Audio output channels 7.1 channels
Component for PC
Motherboard chipset AMD B850
Motherboard chipset family AMD
Motherboard form factor ATX
Product colour Black
Windows operating systems supported Windows 11 x64
Graphics
On-board graphics card No
Internal I/O
CPU fan connector Yes
Number of CPU fan connectors 4
Number of RGB LED pin headers 3
Number of SATA III connectors 4
Number of water pump connectors 1
RGB LED pin header Yes
S/PDIF out connector Yes
Total number of SATA connectors 4
USB 2.0 connectors 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors 1
Memory
ECC сompatibility Non-ECC
Maximum internal memory 256 GB
Memory channels Dual-channel
Memory slots type DIMM
Number of memory slots 4
Supported memory clock speed (max) 8200 MHz
Supported memory clock speeds 4800/5600/6400/8200 MHz
Supported memory types DDR5-SDRAM
Network
Bluetooth Yes
Bluetooth version 5.4
Ethernet interface type 5 Gigabit Ethernet
Ethernet LAN Yes
Top Wi-Fi standard Wi-Fi 7 (802.11be)
Wi-Fi Yes
Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)
Processor
Compatible processor series AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series
Maximum internal memory supported by processor 256 GB
Processor manufacturer AMD
Processor socket Socket AM5
Supported processor sockets Socket AM5
Rear panel I/O ports
DisplayPort version 1.2
DisplayPorts quantity 1
Ethernet LAN (RJ-45) ports 1
HDMI ports quantity 1
HDMI version 2.1
USB 2.0 ports quantity 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 2
Specification
Summary MSI B850 GAMING PLUS WIFI PZ. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, Micro SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 7 (802.11be), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E.... Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: AMD
Category Code MBA
Unit Box Height 0.08
Unit Box Length 0.285
Unit Box Width 0.35
Model B850 GAMING PLUS WIFI PZ
Units per Shipping Box 5
Unit Calculated Volume 0.009405 cubm
Unit Calculated Weight 2.32 kg
Storage controllers
Number of HDDs supported 4
Number of storage drives supported 7
RAID levels 0/1/10/5
RAID support Yes
Supported storage drive interfaces M.2,Micro SATA III
Supported storage drive types HDD & SSD
Weight & dimensions
Depth 304.8 mm
Width 243.84 mm
