IEC/EN 62040-1
IEC/EN 62040-2
IEC/EN 62040-3
CE
UKCA
Ukr
Cm
Compliance certificates
CB/CE/RoHS/WEEE
Waste Electrical and Electronic Equipment (WEEE) compliance
Yes
Design
Control type
Buttons
Display type
LED
Form factor
Tower
Product colour
Black
Features
Auto shut-off
Yes
Efficiency
97 %
Efficiency (ECO mode)
97 %
Input frequency
46/70 Hz
Input operation voltage (max)
284 V
Input operation voltage (min)
161 V
Noise level
25 dB
Number of input phases
1
Number of output phases
1
Output frequency
50/60 Hz
Output operation voltage (max)
284 V
Output operation voltage (min)
161 V
Output power
840 W
Output power capacity
1.3 kVA
Output power factor
0.6
Power consumption (average operating)
26 W
Surge protection
Yes
UPS topology
Standby (Offline)
Waveform
Stepwise
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Other features
Input connection type
C14
Nominal input voltage
220-240 V
Relative humidity
0 - 95 %
Packaging content
Cables included
USB cable
Quick installation guide
Yes
Packaging data
Package type
Box
Ports & interfaces
AC outlet types
C13 coupler
AC outlets quantity
8 AC outlet(s)
Ethernet LAN (RJ-45) ports
1
USB 2.0 ports quantity
2
USB port
Yes
Specification
Summary
Eaton 3P Ellipse UPS. UPS topology: Standby (Offline), Output power capacity: 1.3 kVA, Output power: 840 W. AC outlet types: C13 coupler, AC outlets quantity: 8 AC outlet(s). Battery capacity: 7 Ah, Battery voltage: 12 V. Form factor: Tower, Product colour: Black, Control type: Buttons. Compliance certificates: CB, CE, RoHS, WEEE, Certification: IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 CE UKCA Ukr Cm
Category Code
UPW
Unit Box Height
0.38
Unit Box Length
0.36
Unit Box Width
0.14
Model
3P1300UD
Units per Shipping Box
1
Unit Calculated Volume
0.01915 cubm
Unit Calculated Weight
8.05 kg
Weight & dimensions
Depth
312 mm
Height
305 mm
Weight
7000 g
Width
81 mm
