DAHUA S3226-24ET-375 Switch type Unmanaged Rack mounting Yes

Switch|DAHUA|S3226-24ET-375|Switch type Unmanaged|Rack mounting Yes|24xRJ-45 ports|RJ-45 Ports Type Fast Ethernet (10/100)|24xFast Ethernet (copper) ports quantity|2xCombo SFP ports quantity|Power over Ethernet (PoE) Yes|24xPower over Ethernet (PoE) ports quantity|2xPower over Ethernet 4PPoE (PoE++) ports quantity|Total Power over Ethernet (PoE) budget 375 W|S3226-24ET-375
Price:
233.71 Eur
In stock in LV warehouse

1-2 days

Fast delivery

40+

Countries shipped products

14 years

In IT market

2000+

B2B customers

Aplinkos sąlygos
Darbo temperatūros diapazonas (TT) -10 - 55 °C
Sandėliavimo temperatūros norma (T-T) -40 - 75 °C
Darbo santykinės drėgmės diapazonas 5 - 95 %
Sandėliavimo santykinis drėgmės diapazonas 5 - 95 %
Duomenų perdavimas
Perjungimo pajėgumas 8.8 Gbit/s
Persiuntimo dažnis 6.55 Mpps
Adreso lentelės dydis 8000 įrašai
Jumbo Frames palaikymas Taip
„Jumbo“ kadrai 15000
Paketo buferio atmintis 4 MB
ELKO Internal Logistics Data
Shipping Box Width 9 cm
Unit Brutto Volume 0.01652 cubm
Shipping Box Weight 3.4 kg
Shipping Box Height 34 cm
Shipping Box Depth 54 cm
ELKO Verified Logistics Data
Vieneto aukštis 34 cm
Bruto svoris 3.4 kg
Neto svoris 2.62 kg
Vienetų skaičius vienoje siuntimo dėžėje 1
Vieneto plotis 9 cm
Vieneto gylis 54 cm
Energijos valdymas
Maitinimo šaltinis AC/PoE
Pridėtas maitinimo šaltinis Taip
Maitinimo šaltinių skaičius 1
AC įėjimo įtampa 100 - 240 V
AC įėjimo dažnis 50/60 Hz
Įvesties srovė 7 A
Galios suvartojimas (maks.) 400 W
Konstrukcija
Stovo montavimas Taip
Produkto spalva Juoda
Korpuso medžiaga Metalas
LED indikatoriai Taip
Pakuotės duomenys
Pakuotės tipas „Box“
Pakuotės plotis 342 mm
Pakuotės gylis 540 mm
Pakuotės aukštis 90 mm
Paketo svoris 3220 g
Pakuotės turinys
Pridėti kabeliai AC
Instrukcija Taip
Ryšys
Pagrindinių perjungimo RJ-45 eterneto prievadų skaičius 24
Pagrindinių perjungimo RJ-45 eterneto prievadų tipas Fast Ethernet (10/100)
Greito eterneto (varis) prievadų skaičius 24
Jungtinių SFP prievadų skaičius 2
Aukštynkryčio ryšio prievadų skaičius 2
Maitinimo jungtis AC įėjimo lizdas
Sertifikatai
Atitikties sertifikatai CE
Specification
Name NET SWITCH 26PORT 24POE/S3226-24ET-375 DAHUA
Model name S3226-24ET-375
Summary Dahua Technology PoE S3226-24ET-375. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 24. Switching optical modules type: Gigabit Ethernet. MAC address table: 8000 entries, Switching capacity: 8.8 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at, IEEE.... Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting
Category Code SWI
Unit Box Height 0.34
Unit Box Length 0.54
Unit Box Width 0.09
Šviesolaidis
Optinių perjungimo blokų tipas Gigabitinis eternetas
Svoris ir matmenys
Plotis 220 mm
Ilgis 440 mm
Aukštis 44 mm
Svoris 2620 g
Tinklas
Tinklo standartai IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z
10G parama Ne
Eterneto LAN duomenų perdavimo norma 10,100 Mbit/ai
Valdymo funkcijos
Perjungimo tipas Ne-valdomas
„Power over Ethernet“ (PoE)
Maitinimas per Eternetą (PoE) Taip
Palaikomas maitinimo per eternetą (en. PoE) tipas Active PoE/PoE+/PoE++ (4PPoE)
Maitinimo per Eternetą (PoE) prievadų skaičius 24
Maitinimo eternetu 4PPoE (PoE++) jungčių skaičius 2
Bendrosios galios per Eternetą (PoE) charakteriskos 375 W
