DAHUA CHS4412-8GT-125 Switch type Managed Switch layer L2

Switch|DAHUA|CHS4412-8GT-125|Switch type Managed|Switch layer L2|Form factor Desktop|8xRJ-45 ports|RJ-45 Ports Type Gigabit Ethernet (10/100/1000)|4xFiber ports quantity|Power over Ethernet (PoE) Yes|8xPower over Ethernet (PoE) ports quantity|2xPower over Ethernet 4PPoE (PoE++) ports quantity|Total Power over Ethernet (PoE) budget 125 W|CHS4412-8GT-125
Price:
135.31 Eur
In stock in LV warehouse

1-2 days

Fast delivery

40+

Countries shipped products

14 years

In IT market

2000+

B2B customers

Aplinkos sąlygos
Darbo temperatūros diapazonas (TT) -30 - 65 °C
Sandėliavimo temperatūros norma (T-T) -40 - 85 °C
Darbo santykinės drėgmės diapazonas 10 - 90 %
Sandėliavimo santykinis drėgmės diapazonas 5 - 95 %
Duomenų perdavimas
Perjungimo pajėgumas 24 Gbit/s
Persiuntimo dažnis 17.856 Mpps
Adreso lentelės dydis 8000 įrašai
Jumbo Frames palaikymas Taip
„Jumbo“ kadrai 12288
Paketo buferio atmintis 8.4 MB
ELKO Internal Logistics Data
Shipping Box Width 33 cm
Unit Brutto Volume 0.01238 cubm
Shipping Box Weight 10.3 kg
Shipping Box Height 28 cm
Shipping Box Depth 67 cm
ELKO Verified Logistics Data
Vieneto aukštis 25 cm
Bruto svoris 2.06 kg
Vienetų skaičius vienoje siuntimo dėžėje 5
Vieneto plotis 13 cm
Vieneto gylis 31.5 cm
Energijos valdymas
Maitinimo šaltinis DC/PoE
Pridėtas maitinimo šaltinis Taip
DC įėjimo įtampa 50 - 57 V
Įvesties srovė 2.37 - 2.7 A
Galios suvartojimas (maks.) 134.5 W
Konstrukcija
Stovo montavimas Ne
Forma Desktopas
Produkto spalva Mėlyna
Korpuso medžiaga Metalas
Atstatymo mygtukas Taip
LED indikatoriai Taip
DIN bėgelių blokas Taip
IK kodas IK06
Tarptautinės apsaugos (IP) kodas IP30
Pakuotės duomenys
Pakuotės tipas „Box“
Pakuotės plotis 253.5 mm
Pakuotės gylis 314.5 mm
Pakuotės aukštis 130.5 mm
Paketo svoris 1730 g
Pakuotės turinys
Pridėti kabeliai Energija
Instrukcija Taip
Ryšys
Pagrindinių perjungimo RJ-45 eterneto prievadų skaičius 8
Pagrindinių perjungimo RJ-45 eterneto prievadų tipas Gigabit Ethernet (10/100/1000)
Fibre kanalo portai 4
Šviesolaidžio optinė jungtis SFP
Maitinimo jungtis DC lizdas
Saugumas
DHCP funkcijos DHCP client
Apsauga nuo nesklandaus ryšio Taip
IP-MAC prievado sąsaja Taip
Specification
Name NET SWITCH 12PORT 8POE/CHS4412-8GT-125 DAHUA
Model name CHS4412-8GT-125
Summary Dahua Technology PoE CHS4412-8GT-125. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Switching optical modules type: Gigabit Ethernet. MAC address table: 8000 entries, Switching capacity: 24 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE.... DC input voltage: 50 - 57 V. Power connector: DC-in jack. Power over Ethernet (PoE). Form factor: Desktop
Category Code SWI
Unit Box Height 0.25
Unit Box Length 0.315
Unit Box Width 0.13
Šviesolaidis
Optinių perjungimo blokų tipas Gigabitinis eternetas
Svoris ir matmenys
Plotis 133.4 mm
Ilgis 171.8 mm
Aukštis 42 mm
Svoris 720 g
Tinklas
Tinklo standartai IEEE 802.1Q/IEEE 802.1x/IEEE 802.3/IEEE 802.3ab/IEEE 802.3ad/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3bt/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z
10G parama Ne
Portų mirroring Taip
ARP protokolo (Address Resolution Protocol) įrašai (maks.) 10
Eterneto LAN duomenų perdavimo norma 10,100,1000 Mbit/ai
Nuorodų agregacija Taip
Srauto kontrolės palaikymas Taip
Transliacijos audros valdymas Taip
VLAN palaikymas Taip
Virtualaus vietinio tinklo ypatybės Management VLAN
VLANs skaičius 32
Transliavimo grupiniu adresu ypatybės
Multicast palaikymas Taip
Valdymo funkcijos
Perjungimo tipas Valdomas
Perjungimo sluoksnis L2
Duomenys perduodami į debesies platformą Taip
Web pagrįstas valdymas Taip
Veikimo charakteristikos
Vidutinis laikas tarp trikčių (MTBF) 1179412 h
„Power over Ethernet“ (PoE)
Maitinimas per Eternetą (PoE) Taip
Palaikomas maitinimo per eternetą (en. PoE) tipas Active PoE/PoE+/PoE++ (4PPoE)
Maitinimo per Eternetą (PoE) prievadų skaičius 8
Maitinimo eternetu 4PPoE (PoE++) jungčių skaičius 2
Bendrosios galios per Eternetą (PoE) charakteriskos 125 W
