Power Supply GIGABYTE UD750GM PG5 ICE ATX 3.1 Efficiency 80 PLUS GOLD PFC Active
Power Supply|GIGABYTE|UD750GM PG5 ICE|ATX 3.1|750 Watts|Efficiency 80 PLUS GOLD|PFC Active|MTBF 100000 hours|GP-UD750GMPG5ICE
-
1-2 days Fast delivery
-
40+ Countries shipped products
-
14 years In IT market
-
2000+ B2B customers
Details
| Product colour | White |
| Cooling type | Active |
| Fan diameter | 120 mm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
| Unit Calculated Volume | 0.007986 cubm |
| Shipping Box Weight | 12.6499996185303 kg |
| Shipping Box Height | 28 cm |
| Shipping Box Depth | 62 cm |
| Shipping Box Width | 23 cm |
| Unit Calculated Weight | 2.53 kg |
| Product Net Weight | 2 kg |
| Units per Shipping Box | 5 |
| Unit Width | 25.5 cm |
| Unit Depth | 12 cm |
| Unit Height | 21 cm |
| Warranty period | 5 year(s) |
| Package width | 618 mm |
| Package depth | 269 mm |
| Package height | 211 mm |
| Package weight | 2500 g |
| Package type | Box |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Bearing technology | HYB |
| Mean time between failures (MTBF) | 100000 h |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 610 mm |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| PCI Express power connectors (6+2 pin) | 4 |
| PCI Express power connectors (12+4 pin) | 1 |
| PCI Express power connectors (12+4 pin) cable length | 700 mm |
| PCI Express power cable length | 600 mm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 650 mm |
| Floppy drive power connector | 1 |
| Number of EPS connectors | 2 |
| PCI Express connector | Yes |
| Cabling type | Fully-Modular |
| Total power | 750 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 12 - 6.5 A |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 105 W |
| Combined power (+12V) | 750 W |
| Combined power (+5V) | 105 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 62.5 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 90 % |
| Hold time | 16 ms |
| Power protection features | Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage |
| Category Code | PSU |
| Unit Box Height | 0.21 |
| Unit Box Length | 0.12 |
| Unit Box Width | 0.255 |
| Name | CASE PSU ATX3.1 750W/GP-UD750GM PG5 ICE GIGABYTE |
| Model name | UD750GM PG5 ICE |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Weight | 2340 g |
